CDSD type marine low-temperature quick freezing device

After sorting and plating the fresh fish or frozen items caught on the ship, they are placed in the terminal quick freezing device. The quick freezing device quickly freezes the fresh fish or frozen items at room temperature to the set temperature, and then transfers them to the refrigeration room for refrigeration. Control and security protection:

a) The quick freezing device has an automatic control function. Under automatic conditions, the working time of the quick freezing device is automatically controlled according to the set quick freezing time;

b) The quick freezing device has a manual control function. In manual mode, the solenoid valve can be manually opened and closed to control the working time of the quick freezing device;

Composition: The quick freezing device consists of a compression condensing unit and a hydraulic flat freezing device.

The compression condensing unit consists of a marine refrigeration compressor, a marine condenser, an oil separator, a gas-liquid separator, a drying filter, a liquid storage tank, an electrical control box, and a frame. The compression condensing unit equipment is assembled on a frame, greatly reducing the installation workload and space occupation on board, while also facilitating operation. The hydraulic flat plate quick freezing device consists of a flat plate quick freezing device, hydraulic device, periphery, and valve group (including solenoid valve, electronic expansion valve, globe valve, etc.). The hydraulic flat freezing device is assembled on a base, which greatly reduces the installation workload and space occupation on the ship, and is also convenient to operate. The quick freezing device has high automation level, large refrigeration capacity, large amount of frozen food, fast freezing speed, compact structure, and occupies less space; The high degree of automation in electrical control configuration is conducive to reducing the labor intensity of operators and saving operating energy consumption, thereby reducing operating costs.
